Fuses
A fuse is a safety device that is used to protect electrical circuits from overloading and short-circuits. It works by breaking the flow of electrical current in the event of an overload or short-circuit. This helps to prevent damage to electrical equipment, minimize the risk of electrical fires, and protect people from electric shock.
- Product
- Qty in Cart
- Price
-
Contact Us For Quote
Bussmann FWH-50B Distribution Fuses
MSRP $171.60Surplus $73.15SKU: F16-5883 Brand: Bussmann MPN: FWH-50B UPC: 5171279577 Shipping Weight: 0.15 lbs. Shipping Height: 1.00 In. Shipping Length: 4.00 In. Shipping Width: 1.00 In...- SKU:
- F16-5883
- TS PIK:
- 110618041
- Current Rating:
- 50 A
- Terminal Type:
- Blade
- Interrupting Rating:
- 200 kA (Symmetrical), 50 kA at 500 VDC
- Approval:
- UL, CSA, CE
- Diameter:
- 0.813
- Data Sheet:
- Eaton-Bussmann_00619_1_DATA.pdf
- Voltage Rating:
- 500 VAC/DC
- Length:
- 3.188
- Characteristics:
- High Speed
- Type:
- Round
- Short Description:
- 0.81" x 3.19", 500 VAC/VDC, 50 A, 200/50 kA Interrupt Rating, Blade Terminal, High Speed, Bolted Tag, North American Fuse
- Series:
- FWH
- Catalog:
- Eaton-Bussmann_00349_4_8_CAT.pdf
- Country of Origin:
- Mexico
MSRP $171.60Surplus $73.15 -
Bussmann JJN-150 Fuse Accessories
MSRP $126.51Surplus $35.74Bussmann JJN-150 Fuse Accessories​ ARCA SKU: F16-3048 Brand: Bussmann MPN: JJN-150 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In...- SKU:
- F16-3048
- Catalog:
- Eaton-Bussmann_00350_36_CAT.pdf
- Length:
- 2.44
- Diameter:
- 0.88
- Approval:
- UL, CSA C22.2, CE
- Short Description:
- 0.88" x 2.44", 300 VAC, 160 VDC, 150 A, 200/20 kA Interrupt Rating, Bolted Blade Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (1 per Carton)
- Series:
- JJN
- Data Sheet:
- Eaton-Bussmann_00313_1-4_DATA.pdf
- Terminal Type:
- Bolted Blade
- Voltage Rating:
- 300 VAC, 160 VDC
- Characteristics:
- Fast Acting
- Type:
- Class T
- Interrupting Rating:
- 200 kA (Symmetrical), 20 kA (DC)
- Current Rating:
- 150 A
- Country of Origin:
- Mexico
MSRP $126.51Surplus $35.74 -
Contact Us For Quote
Bussmann S-20 Fuse Accessories
MSRP $9.85Surplus $3.74Bussmann S-20 Fuse Accessories​ ARCA SKU: F16-3177 Brand: Bussmann MPN: S-20 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In...- SKU:
- F16-3177
MSRP $9.85Surplus $3.74 -
Ferraz Shawmut AG3 Fuse Accessories
MSRP $22.35Surplus $3.18Ferraz Shawmut AG3 Fuse Accessories​ ARCA SKU: F16-3824 Brand: Ferraz Shawmut MPN: AG3 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In...- SKU:
- F16-3824
- Current Rating:
- 3 A
- Type:
- Class G
- Approval:
- UL 248-5, CSA C22.2
- Interrupting Rating:
- 100 kA (AC)
- Length:
- 1.31
- Short Description:
- 0.41" x 1.31", 600 VAC, 3 A, 100 kA AC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class G, Current Limiting, Time Delay, Low Vage UL Power Fuse (4 per Pack)
- Diameter:
- 0.41
- Catalog:
- Mersen_00086_195_CAT.pdf
- CAD Drawings:
- Mersen_00230_1_CAD.pdf
- Terminal Type:
- Ferrule
- Characteristics:
- Time Delay, Current Limiting
- Series:
- AG
- Voltage Rating:
- 600 VAC 50/60 Hertz
- Data Sheet:
- Mersen_00062_PF29_DATA.pdf
MSRP $22.35Surplus $3.18 -
Ferraz Shawmut AJT10 Fuses EA
MSRP $51.06Surplus $18.93SKU: F16-3973 Brand: Ferraz Shawmut MPN: AJT10 UPC: 78200196272 Shipping Weight: 1.00 lbs. Shipping Height: 2.00 In. Shipping Length: 5.00 In. Shipping Width: 3.00 In...- SKU:
- F16-3973
- Terminal Type:
- Ferrule
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Type:
- Class J
- Characteristics:
- Time Delay, Current Limiting
- Current Rating:
- 10 A
- Short Description:
- 0.81" x 2.25", 600 VAC 50/60 Hz/500 VDC, 10 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (5 per Pack)
- Series:
- AJT
- Catalog:
- Mersen_00086_192_CAT.pdf
- CAD Drawings:
- Mersen_00175_1_CAD.pdf
- Data Sheet:
- Mersen_00063_1_2_DATA.pdf
- TS PIK:
- 110477773
- Length:
- 2.25
- Voltage Rating:
- 600 VAC 50/60 Hertz, 500 VDC
- Diameter:
- 0.813
- Approval:
- UL 248/248-8, CSA C22.2
MSRP $51.06Surplus $18.93 -
Ferraz Shawmut AJT3 Distribution Fuses
MSRP $31.58Surplus $9.87SKU: F16-2339 Brand: Ferraz Shawmut MPN: AJT3 UPC: 78200196255 Shipping Weight: 0.10 lbs. Shipping Height: 1.00 In. Shipping Length: 3.00 In. Shipping Width: 1.00 In...- SKU:
- F16-2339
- Series:
- AJT
- Type:
- Class J
- Approval:
- UL 248/248-8
- Volts:
- 600 VAC
- Amps:
- 32 A
- Interrupting Rating:
- 200 kA
- Terminal Type:
- Ferrule
- Length:
- 2-1/4
- Diameter:
- 13/16
- Characteristics:
- Time Delay
- Time Delay:
- Voltage Rating
- Short Description:
- 0.81" x 2.25", 600 VAC 50/60 Hz/500 VDC, 3 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Class J, Current Limiting, Time Delay
- Catalog:
- Mersen_00086_192_CAT.pdf
- Data Sheet:
- Mersen_00063_1_2_DATA.pdf
- CAD Drawing:
- Mersen_00175_1_CAD.pdf
- CAD Drawings:
- Mersen_00175_1_CAD.pdf
- Current Rating:
- 3 A
- Voltage Rating:
- 600 VAC, 500 VDC
- TS PIK:
- 110477764
MSRP $31.58Surplus $9.87 -
Ferraz Shawmut AJT4N Fuses EA
MSRP $62.35Surplus $20.60SKU: F16-3978 Brand: Ferraz Shawmut MPN: AJT4N UPC: 78200149808 Shipping Weight: 1.10 lbs. Shipping Height: 2.00 In. Shipping Length: 5.00 In. Shipping Width: 3.00 In...- SKU:
- F16-3978
- Short Description:
- 600V 4A J TD NON-IND
- Current Rating:
- 4 A
- TS PIK:
- 128088304
MSRP $62.35Surplus $20.60 -
Ferraz Shawmut ATDR15 Fuses
MSRP $200.00Surplus $16.26Ferraz Shawmut ATDR15 Fuses​ ARCA SKU: F16-2648 Brand: Ferraz Shawmut MPN: ATDR15 UPC: 78200190110 Shipping Weight: 0.20 lbs. Shipping Height: 1.00 In. Shipping Length: 2...- SKU:
- F16-2648
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Short Description:
- 0.41" x 1.5", 600 VAC, 300 VDC, 15 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Power Fuse
- Type:
- Class CC
- Series:
- ATDR
- Catalog:
- Mersen_00086_194_CAT.pdf
- Terminal Type:
- Ferrule
- CAD Drawings:
- Mersen_00134_1_CAD.pdf
- Current Rating:
- 15 A
- Characteristics:
- Time Delay, Current Limiting
- Data Sheet:
- Mersen_00064_1_2_DATA.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 300 VDC
- Diameter:
- 0.41
- Length:
- 1.5
MSRP $200.00Surplus $16.26 -
Ferraz Shawmut ATM15 Fuses
MSRP $200.00Surplus $12.43Ferraz Shawmut ATM15 Fuses​ ARCA SKU: F16-2378 Brand: Ferraz Shawmut MPN: ATM15 UPC: 78200190069 Shipping Weight: 0.25 lbs. Shipping Height: 1.00 In. Shipping Length: 3...- SKU:
- F16-2378
- Short Description:
- 0.41" x 1.5", 600 VAC/VDC, 15 A, 100 kA Interrupt Rating, GMG Body/Insulating, Tin Plated Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Low Vage, Fast Acting, Midget Fuse
- CAD Drawings:
- Mersen_00135_1_CAD.pdf
- Current Rating:
- 15 A
- Terminal Type:
- Ferrule
- Series:
- ATM
- Interrupting Rating:
- 100 kA (AC)
- Catalog:
- Mersen_00180_MF3_CAT.pdf
- Characteristics:
- Fast Acting
- Length:
- 1.5
- Voltage Rating:
- 600 VAC 50/60 Hertz, 600 VDC
- Diameter:
- 0.41
- Approval:
- UL 248-14, CSA C22.2
MSRP $200.00Surplus $12.43 -
Ferraz Shawmut OTM30 Fuse Accessories
MSRP $8.86Surplus $2.78Ferraz Shawmut OTM30 Fuse Accessories​ ARCA SKU: F16-3583 Brand: Ferraz Shawmut MPN: OTM30 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0...- SKU:
- F16-3583
- Short Description:
- 0.41" x 1.5", 250 VAC, 30 A, 10 kA Interrupt, Paper Body, Tin Plated Copper Ferrule Terminal, Clip Mount, One Time, Fast Acting, Midget Fuse
- Diameter:
- 0.41
- Voltage Rating:
- 250 VAC
- Current Rating:
- 30 A
- Series:
- OTM
- Interrupting Rating:
- 10 kA
- Length:
- 1.5
- Characteristics:
- Fast Acting, One Time
- CAD Drawings:
- Mersen_00417_1_CAD.pdf
- Data Sheet:
- Mersen_00083_MF5_DATA.pdf
- Terminal Type:
- Ferrule
- Catalog:
- Mersen_00086_199_CAT.pdf
- Approval:
- UL 248-14, CSA C22.2
MSRP $8.86Surplus $2.78 -
Ferraz Shawmut TR200R Fuses
MSRP $137.80Surplus $46.82SKU: F16-4871 Brand: Ferraz Shawmut MPN: TR200R UPC: 78200174808 Shipping Weight: 0.80 lbs. Shipping Height: 2.00 In. Shipping Length: 8.00 In. Shipping Width: 2.00...- SKU:
- F16-4871
- TS PIK:
- 528370
- Current Rating:
- 200 A
- Interrupting Rating:
- 200 kA (AC), 20 kA (DC)
- Short Description:
- 1.56" x 7.13", 250 VAC 50/60 Hz, 250 VDC, 200 A, 200 kA AC/20 kA DC Interrupt Rating, Fiberglass Body, Tin Plated Copper Blade Terminal, Class RK5, Clip Mount, Time Delay, Low Vage, UL Power Fuse
- CAD Drawings:
- Mersen_00291_1_CAD.pdf
- Characteristics:
- Time Delay, Low Vage
- Terminal Type:
- Blade
- Series:
- TR-R
- Type:
- Class RK5
- Diameter:
- 1.56
- Length:
- 7.13
- Voltage Rating:
- 250 VAC 50/60 Hertz, 250 VDC
- Approval:
- UL 248-12, CSA C22.2
MSRP $137.80Surplus $46.82 -
Gould TRM5 Fuse Accessories
MSRP $200.00Surplus $5.37SKU: F16-2460 Brand: Gould MPN: TRM5 UPC: 78200174345 Shipping Weight: 0.20 lbs. Shipping Height: 1.00 In. Shipping Length: 3.00 In. Shipping Width: 2.00 In. Product...- SKU:
- F16-2460
- TS PIK:
- 528306
- Series:
- TRM
- Interrupting Rating:
- 10 kA (AC)
- Terminal Type:
- Ferrule
- Characteristics:
- 12 Second Time Delay (200 Percent Rated Load)
- Length:
- 1.5
- Voltage Rating:
- 250 VAC
- CAD Drawings:
- Mersen_00144_1_CAD.pdf
- Catalog:
- Mersen_00180_MF4_CAT.pdf
- Diameter:
- 0.41
- Current Rating:
- 5 A
- Approval:
- UL 248-14, CSA C22.2
- Short Description:
- 0.41" x 1.5", 250 VAC, 5 A, 10 kA Interrupt Rating, GMG Body/Insulating, Tin Plated Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Low Vage, Time Delay, Midget Fuse
MSRP $200.00Surplus $5.37 -
Contact Us For Quote
Littelfuse LLSRK080ID Fuse Accessories
MSRP $176.07Surplus $51.73Littelfuse LLSRK080ID Fuse Accessories​ ARCA SKU: F16-4269 Brand: Littelfuse MPN: LLSRK080ID UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0...- SKU:
- F16-4269
- Voltage Rating:
- 600 VAC, 300 VDC
- Terminal Type:
- Blade
- Characteristics:
- Time Delay, Dual Element, Indicating
- Current Rating:
- 80 A
- Country of Origin:
- Mexico
- Type:
- Indicating, Class RK1
- Interrupting Rating:
- 200 kA Symmetrical (AC), 20 kA (DC)
- Data Sheet:
- Littelfuse_00244_1-3_DATA.pdf
- Catalog:
- Littelfuse_00189_2_4_14-16_20_CAT.pdf
- Series:
- LLSRK_ID
- Short Description:
- 1-5/16" x 7-7/8", 600 VAC/300 VDC, 80 A, 200 kA Symmetrical AC, 300 kA Symmetrical/Self-Certified, 20 kA DC, Blade Terminal, Dual Element, Indicating, Class RK1, Knife-Blade, Time Delay Fuse
- Length:
- 7-7/8
- Approval:
- UL 248-12, CSA, CE, QPL-WF-1814
- Diameter:
- 1-5/16
MSRP $176.07Surplus $51.73 -
Mersen TR110R Fuse Accessories EA
MSRP $99.02Surplus $47.33Mersen TR110R Fuse Accessories EA​ ARCA SKU: E30-7828 Brand: Mersen MPN: TR110R UPC: 78200174804 Shipping Weight: 0.70 lbs. Shipping Height: 1.00 In. Shipping Length: 7...- SKU:
- E30-7828
- Series:
- TR-R
- Terminal Type:
- Blade
- Catalog:
- Mersen_00086_191_CAT.pdf
- Data Sheet:
- Mersen_00090_PF12_PF13_DATA.pdf
- CAD Drawings:
- Mersen_00291_1_CAD.pdf
- Short Description:
- 1.56" x 7.13", 250 VAC 50/60 Hz/250 VDC, 110 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (1 per Pack)
- Type:
- Class RK5
- Current Rating:
- 110 A
- Voltage Rating:
- 250 VAC/DC
- Characteristics:
- Time Delay
- Length:
- 7-1/8
MSRP $99.02Surplus $47.33 -
Mersen USGCC1 Fuse Blocks and Holders
MSRP $29.47Surplus $11.93Mersen USGCC1 Fuse Blocks and Holders​ ARCA SKU: F16-6310 Brand: Mersen MPN: USGCC1 UPC: 78200143801 Shipping Weight: 0.15 lbs. Shipping Height: 3.00 In. Shipping...- SKU:
- F16-6310
- TS PIK:
- 124992448
MSRP $29.47Surplus $11.93 -
Ferraz Shawmut AJT90 Fuse Accessories 600V EA
MSRP $213.63Surplus $73.19Ferraz Shawmut AJT90 Fuse Accessories 600V EA​ ARCA SKU: F16-3982 Brand: Ferraz Shawmut MPN: AJT90 UPC: 78200196268 Shipping Weight: 0.75 lbs. Shipping Height: 4.00 In. Shipping...- SKU:
- F16-3982
- Terminal Type:
- Blade
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Characteristics:
- Time Delay, Current Limiting
- Type:
- Class J
- CAD Drawings:
- Mersen_00366_1_CAD.pdf
- Current Rating:
- 90 A
- Data Sheet:
- Mersen_00063_1_2_DATA.pdf
- Catalog:
- Mersen_00086_192_CAT.pdf
- Series:
- AJT
- Length:
- 4.63
- Diameter:
- 1.063
- Approval:
- UL 248/248-8, CSA C22.2
- Voltage Rating:
- 600 VAC 50/60 Hertz, 400 VDC
MSRP $213.63Surplus $73.19 -
Buss Fuses LPS-RK-70SP Fuses
MSRP $165.00Surplus $61.46SKU: F16-6347 Brand: Buss Fuses MPN: LPS-RK-70SP UPC: Shipping Weight: 0.40 lbs. Shipping Height: 1.00 In. Shipping Length: 8.00 In. Shipping Width: 1.00 In...- SKU:
- F16-6347
- Series:
- LPS-RK
- Characteristics:
- 10 Second Time Delay (500 Percent Rated Load), Current Limiting, Non-Indicating, Dual Element
- Catalog:
- Eaton-Bussmann_00349_1_24_1_25_CAT.pdf
- Terminal Type:
- Blade
- Data Sheet:
- Eaton-Bussmann_00739_1-4_DATA.pdf
- Short Description:
- 1.11" x 7.88", 600 VAC, 300 VDC, 70 A, 300/100 kA Interrupt Rating, Blade Terminal, Class RK1, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)
- Interrupting Rating:
- 300 kA (AC), 100 kA (DC)
- Type:
- Class RK1
- Current Rating:
- 70 A
- Voltage Rating:
- 600 VAC, 300 VDC
- Interrupt Rating:
- 300/100 kA
- Approval:
- UL, CSA C22.2, CE
- Length:
- 7.88
- Diameter:
- 1.11
- Country of Origin:
- Mexico
MSRP $165.00Surplus $61.46 -
Bussmann JJS-200 Distribution Fuses
MSRP $277.31Surplus $131.72SKU: F16-5953 Brand: Bussmann MPN: JJS-200 UPC: 5171262803 Shipping Weight: 0.20 lbs. Shipping Height: 2.00 In. Shipping Length: 4.00 In. Shipping Width: 2.00 In...- SKU:
- F16-5953
- TS PIK:
- 110616208
- Characteristics:
- Fast Acting, Current Limiting, Non-Indicating
- Interrupting Rating:
- 200 kA (AC)
- Series:
- JJS
- Current Rating:
- 200 A
- Short Description:
- 0.88" x 3.25", 600 VAC, 200 A, 200 kA Interrupt Rating, Bolted Blade Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (1 per Carton)
- Approval:
- UL 248-15, CSA C22.2, CE
- Length:
- 3.25
- Type:
- Class T
- Data Sheet:
- Eaton-Bussmann_00116_1-4_DATA.pdf
- Catalog:
- Eaton-Bussmann_00349_1_31_CAT.pdf
- Terminal Type:
- Bolted Blade
- Diameter:
- 0.88
- Voltage Rating:
- 600 VAC
- Country of Origin:
- Mexico
MSRP $277.31Surplus $131.72 -
Bussmann LPS-RK-100SP Fuse Accessories
MSRP $152.77Surplus $45.61Bussmann LPS-RK-100SP Fuse Accessories​ ARCA SKU: F16-2309 Brand: Bussmann MPN: LPS-RK-100SP UPC: 05171254845 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping...- SKU:
- F16-2309
- Series:
- LPS-RK
- Catalog:
- Eaton-Bussmann_00349_1_24_1_25_CAT.pdf
- Type:
- Class RK1
- Short Description:
- 1.11" x 7.88", 600 VAC, 300 VDC, 100 A, 300/100 kA Interrupt Rating, Blade Terminal, Class RK1, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)
- Terminal Type:
- Blade
- Data Sheet:
- Eaton-Bussmann_00739_1-4_DATA.pdf
- Current Rating:
- 100 A
- Interrupting Rating:
- 300 kA (AC), 100 kA (DC)
- Diameter:
- 1.11
- Length:
- 7.88
- Approval:
- UL, CSA C22.2, CE
- Voltage Rating:
- 600 VAC, 300 VDC
- Characteristics:
- 10 Second Time Delay (500 Percent Rated Load), Current Limiting, Non-Indicating, Dual Element
- Country of Origin:
- Mexico
MSRP $152.77Surplus $45.61 -
Ferraz Shawmut A2D40R Fuses EA
MSRP $38.17Surplus $12.41Ferraz Shawmut A2D40R Fuses EA​ ARCA SKU: F16-3695 Brand: Ferraz Shawmut MPN: A2D40R UPC: 78200199091 Shipping Weight: 0.15 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- F16-3695
- Current Rating:
- 40 A
- CAD Drawings:
- Mersen_00173_1_CAD.pdf
- Catalog:
- Mersen_00086_189_CAT.pdf
- Type:
- Class RK1
- Data Sheet:
- Mersen_00050_PF8_PF9_DATA.pdf
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Characteristics:
- Time Delay
- Series:
- A2D-R
- Terminal Type:
- Ferrule
- Short Description:
- 0.81" x 3", 250 VAC/VDC, 40 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (10 per Pack)
- Voltage Rating:
- 250 VAC/DC
- Approval:
- UL 248/248-12, CSA C22.2
- Length:
- 3
- Diameter:
- 13/16
- Country of Origin:
- Mexico
MSRP $38.17Surplus $12.41
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
