Fuses
A fuse is a safety device that is used to protect electrical circuits from overloading and short-circuits. It works by breaking the flow of electrical current in the event of an overload or short-circuit. This helps to prevent damage to electrical equipment, minimize the risk of electrical fires, and protect people from electric shock.
- Product
- Qty in Cart
- Price
-
Contact Us For Quote
Bussmann AGC-20 Fuses
Surplus $4.95Bussmann AGC-20 Fuses​ ARCA SKU: F16-3181 Brand: Bussmann MPN: AGC-20 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping...- SKU:
- F16-3181
- Interrupting Rating:
- 1000 A at 32 VAC
- Short Description:
- 1/4" x 1-1/4", 32 VAC, 20 A, 1 kA Interrupt Rating, Ferrule Terminal, Fast Acting, Glass Tube, Automotive Electronic Fuse (5 per Pack)
- Characteristics:
- Fast Acting
- Terminal Type:
- Ferrule
- Series:
- AGC
- Type:
- Glass Tube
- Current Rating:
- 20 A
Surplus $4.95 -
Contact Us For Quote
Ferraz Shawmut RFS1 Fuse Accessories 600V
MSRP $101.61Surplus $36.93Ferraz Shawmut RFS1 Fuse Accessories 600V​ ARCA SKU: E30-7865 Brand: Ferraz Shawmut MPN: RFS1 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping...- SKU:
- E30-7865
MSRP $101.61Surplus $36.93 -
Gould TR100R Distribution Fuses
MSRP $62.65Surplus $18.23SKU: F16-4140 Brand: Gould MPN: TR100R UPC: 78200174801 Shipping Weight: 0.30 lbs. Shipping Height: 1.00 In. Shipping Length: 7.00 In. Shipping Width: 6.00 In...- SKU:
- F16-4140
- Interrupting Rating:
- 200 kA (AC), 20 kA (DC)
- Catalog:
- Mersen_00180_PF12_PF13_CAT.pdf
- CAD Drawings:
- Mersen_00290_1_CAD.pdf
- Current Rating:
- 100 A
- Type:
- Class RK5
- Short Description:
- 0.06" x 5.88", 250 VAC/VDC, 50/60 Hz, 100 A, 200 kA Interrupt Rating, Poly Tube Body/Insulating, Tin Plated Copper Connection/Terminal, Blade Terminal, Clip Mount, Class RK5, Low Vage, Current Limiting, Time Delay Fuse
- Terminal Type:
- Blade
- Characteristics:
- Time Delay
- Series:
- TR-R
- TS PIK:
- 528365
- Length:
- 5-7/8
- Voltage Rating:
- 250 VAC/DC
- Diameter:
- 1-1/16
- Approval:
- UL 248-12, CSA C22.2
MSRP $62.65Surplus $18.23 -
Bussmann HEB-AA Fuse Accessories EA
MSRP $73.96Surplus $23.74Bussmann HEB-AA Fuse Accessories EA​ ARCA SKU: F16-5922 Brand: Bussmann MPN: HEB-AA UPC: 5171271820 Shipping Weight: 0.10 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- F16-5922
- TS PIK:
- 110617258
- Series:
- HEB
- Catalog:
- Eaton-Bussmann_00349_8_51_8_52_CAT.pdf
- Fuse Type:
- 13/32 x 1-1/2
- Terminal Type:
- Crimp (Line/Load Side)
- Short Description:
- 600 V, 30 A, 1-Pole, 13/32" x 1-1/2" Fuse, 16 to 12 AWG, 16 to 8 AWG Copper Line/Load, Crimp Line/Load, In-Line, Non-Breakaway, Fuse Holder
- Type:
- In-Line, Non-Breakaway
- Number of Poles:
- 1
- Data Sheet:
- Eaton-Bussmann_00288_1-6_DATA.pdf
- Voltage Rating:
- 600 V
- Fuse Current Rating:
- 30 A
MSRP $73.96Surplus $23.74 -
Mersen R422 Fuse Reducers and Clips EA
MSRP $533.07Surplus $250.00Mersen R422 Fuse Reducers and Clips EA​ ARCA SKU: F16-3597 Brand: Mersen MPN: R422 UPC: 78200175242 Shipping Weight: 0.30 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- F16-3597
- Installation/Operator:
- LIXILGroupCorp-AmericanStandardBrand_00299_INST.pdf
- Series:
- R422
- Short Description:
- 1/2" x 1/2", NPT x NPT, Solid Brass, 2-Way, In-Wall, Shower Diverter Rough Valve
- Type:
- 2-Discrete Function, 2-Way, In-Wall
MSRP $533.07Surplus $250.00 -
Bussmann NON-100 Fuses
MSRP $66.76Surplus $3.16SKU: F16-3012 Brand: Bussmann MPN: NON-100 UPC: 05171210168 Shipping Weight: 0.30 lbs. Shipping Height: 2.00 In. Shipping Length: 6.00 In. Shipping Width: 2.00 In...- SKU:
- F16-3012
- TS PIK:
- 124389
- Series:
- NON
- Short Description:
- 1.06" x 5.88", 250 VAC, 125 VDC, 100 A, 10 kA Interrupt Rating, Blade Terminal, Class K5/H, 1-Time, Non-Current Limiting, General Purpose Fuse (5 per Carton)
- Data Sheet:
- Eaton-Bussmann_00320_1_2_DATA.pdf
- Characteristics:
- One Time, Non-Current Limiting, General Purpose
- Type:
- Class H
- Current Rating:
- 100 A
- Interrupting Rating:
- 10 kA (AC/DC)
- Catalog:
- Eaton-Bussmann_00349_1_21_CAT.pdf
- Voltage Rating:
- 250 VAC/125 VDC
- Interrupt Rating:
- 10 kA
- Length:
- 7.9
- Diameter:
- 1.34
- Country of Origin:
- Mexico
- Main Category:
- Fuses
- Approval:
- UL 248-9, CSA, CE
MSRP $66.76Surplus $3.16 -
Ferraz Shawmut AG10 Fuse Accessories 4BOX
MSRP $25.00Surplus $6.29Ferraz Shawmut AG10 Fuse Accessories 4BOX​ ARCA SKU: F16-2146 Brand: Ferraz Shawmut MPN: AG10 UPC: 78200190513 Shipping Weight: 0.10 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- F16-2146
- TS PIK:
- 110477237
MSRP $25.00Surplus $6.29 -
Ferraz Shawmut ATDR30 Fuses
MSRP $41.00Surplus $12.89Ferraz Shawmut ATDR30 Fuses​ ARCA SKU: F16-2335 Brand: Ferraz Shawmut MPN: ATDR30 UPC: 78200190870 Shipping Weight: 0.20 lbs. Shipping Height: 1.00 In. Shipping Length: 2...- SKU:
- F16-2335
- Approval:
- UL 248/248-4
- Approval:
- CSA C22.2
- Approval:
- CE
- Characteristics:
- Time Delay
- Amps:
- 30 A
- Diameter:
- 0.41
- Interrupting Rating:
- 200 kA (AC)
- Interrupting Rating:
- 100 Kiloamp (DC)
- Length:
- 1.5
- Terminal Type:
- Ferrule
- Type:
- Class CC Rejection
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 300 VDC
- Short Description:
- 0.41" x 1.5", 600 VAC, 300 VDC, 30 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Power Fuse
- Series:
- ATDR
- Data Sheet:
- Mersen_00064_1_2_DATA.pdf
- CAD Drawing:
- Mersen_00134_1_CAD.pdf
- Current Rating:
- 30 A
- Catalog:
- Mersen_00086_194_CAT.pdf
- CAD Drawings:
- Mersen_00134_1_CAD.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 300 VDC
MSRP $41.00Surplus $12.89 -
Mersen TR150R Fuses EA
MSRP $285.00Surplus $23.66Mersen TR150R Fuses EA​ ARCA SKU: F16-2356 Brand: Mersen MPN: TR150R UPC: 78200174806 Shipping Weight: 0.80 lbs. Shipping Height: 2.00 In. Shipping Length: 7.00 In...- SKU:
- F16-2356
- Approval:
- UL 248-12
- Characteristics:
- Time Delay
- Amps:
- 150 A
- Diameter:
- 1-9/16
- Interrupting Rating:
- 200 kA
- Length:
- 7-1/8
- Terminal Type:
- Blade
- Time Delay:
- Voltage Rating
- Type:
- Class RK5
- Volts:
- 250 VAC/DC
- Short Description:
- 1.56" x 7.13", 250 VAC/VDC, 50/60 Hz, 150 A, 200 kA Interrupt Rating, Poly Tube Body/Insulating, Tin Plated Copper Connection/Terminal, Blade Terminal, Clip Mount, Class RK5, Low Voltage, Current Limiting, Time Delay Fuse
- Series:
- TR-R
- CAD Drawing:
- Mersen_00291_1_CAD.pdf
- Current Rating:
- 150 A
- Catalog:
- Mersen_00180_PF12_PF13_CAT.pdf
- CAD Drawings:
- Mersen_00291_1_CAD.pdf
- Voltage Rating:
- 250 VAC/DC
MSRP $285.00Surplus $23.66 -
Ferraz Shawmut TR400R Fuse Accessories 250V EA
MSRP $248.46Surplus $90.64Ferraz Shawmut TR400R Fuse Accessories 250V EA​ ARCA SKU: F16-3608 Brand: Ferraz Shawmut MPN: TR400R UPC: 78200174815 Shipping Weight: 1.85 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- F16-3608
- Series:
- TR-R
- Type:
- Class RK5
- Current Rating:
- 400 A
- Diameter:
- 2-1/16
- Interrupting Rating:
- 200 kA (AC), 20 kA (DC)
- Terminal Type:
- Blade
- Data Sheet:
- Mersen_00090_PF12_PF13_DATA.pdf
- Characteristics:
- Time Delay
- Voltage Rating:
- 250 VAC/DC
- Catalog:
- Mersen_00086_191_CAT.pdf
- Approval:
- UL 248-12, CSA C22.2
- Short Description:
- 2.06" x 8.63", 250 VAC 50/60 Hz/250 VDC, 400 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (1 per Pack)
- Length:
- 8-5/8
- CAD Drawings:
- Mersen_00257_1_CAD.pdf
MSRP $248.46Surplus $90.64 -
Contact Us For Quote
Mersen FEB-11-11-BA Fuse Accessories 30A 600V
MSRP $234.00Surplus $40.58Mersen FEB-11-11-BA Fuse Accessories 30A 600V​ ARCA SKU: F16-2095 Brand: Mersen MPN: FEB-11-11-BA UPC: Shipping Weight: 0.15 lbs. Shipping Height: 1.00 In. Shipping Length: 6...- SKU:
- F16-2095
- Approval:
- UL
- Approval:
- CSA
- Amps:
- 30 A
- Fuse Type:
- 13/32 Inch x 1-1/2 Inch Midget
- Material:
- Polyethylene
- Poles:
- 1
- Terminal Type:
- Crimp (Line/Load Side)
- Type:
- In-Line Breakaway
- Volts:
- 600 VAC/DC
- Short Description:
- 5.8" x 1" x 1", 600 VAC/VDC, 30 A, (1) 12 to 8 AWG/(2) 14 to 12 AWG Solid/Stranded Copper, 1-Pole, Polyethylene Body, Clip-In Installation, In-Line, Midget Fuse Holder
- Series:
- FEB
- Data Sheet:
- Mersen_00180_FB36-FB39_DATA.pdf
- CAD Drawing:
- Mersen_00375_1_CAD.pdf
MSRP $234.00Surplus $40.58 -
Contact Us For Quote
Mersen A4J250 Fuses
MSRP $911.08Surplus $102.74SKU: F16-3467 Brand: Mersen MPN: A4J250 UPC: 78200196039 Shipping Weight: 1.85 lbs. Shipping Height: 2.00 In. Shipping Length: 6.00 In. Shipping Width: 2.00 In...- SKU:
- F16-3467
- Short Description:
- 2.12" x 7.13", 600 VAC/300 VDC, 250 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Brass Alloy Blade Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Current Rating:
- 250 A
- Catalog:
- Mersen_00086_193_CAT.pdf
- Series:
- A4J
- Characteristics:
- Fast Acting
- Type:
- Class J
- CAD Drawings:
- Mersen_00196_1_CAD.pdf
- Terminal Type:
- Blade
- Data Sheet:
- Mersen_00056_PF22_PF23_DATA.pdf
- TS PIK:
- 530038
- Diameter:
- 2-1/8
- Voltage Rating:
- 600 VAC, 300 VDC
- Length:
- 7-1/8
- Approval:
- UL 248/248-8, CSA C22.2
MSRP $911.08Surplus $102.74 -
Mersen ATQR1/4 Fuses
MSRP $101.00Surplus $9.52Mersen ATQR1/4 Fuses​ ARCA SKU: F16-2096 Brand: Mersen MPN: ATQR1/4 UPC: 78200190630 Shipping Weight: 0.15 lbs. Shipping Height: 1.00 In. Shipping Length: 1.00 In...- SKU:
- F16-2096
- Approval:
- UL 248/248-4
- Approval:
- CSA C22.2
- Approval:
- CE
- Characteristics:
- Time Delay
- Amps:
- 0.25 A
- Diameter:
- 0.41
- Interrupting Rating:
- 200 kA (AC)
- Interrupting Rating:
- 100 Kiloamp (DC)
- Length:
- 1.5
- Terminal Type:
- Ferrule
- Type:
- Class CC Rejection
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 300 VDC
- Short Description:
- 0.41" x 1.5", 600 VAC, 300 VDC, 1/4 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse
- Series:
- ATQR
- Data Sheet:
- Mersen_00068_PF26_PF27_DATA.pdf
- CAD Drawing:
- Mersen_00232_1_CAD.pdf
- Current Rating:
- 0.25 A
- CAD Drawings:
- Mersen_00232_1_CAD.pdf
- Catalog:
- Mersen_00086_194_CAT.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 300 VDC
MSRP $101.00Surplus $9.52 -
Edison HCTR15 Fuses
MSRP $33.72Surplus $18.02SKU: E30-7753 Brand: Edison MPN: HCTR15 UPC: 78263480212 Shipping Weight: 0.15 lbs. Shipping Height: 1.00 In. Shipping Length: 2.00 In. Shipping Width: 2.00 In...- SKU:
- E30-7753
- Catalog:
- Eaton-Bussmann_00210_3_4_CAT.pdf
- Characteristics:
- Time Delay
- Series:
- HCTR
- Interrupting Rating:
- 200 kA (Symmetrical)
- Data Sheet:
- Eaton-Bussmann_00802_1_2_DATA.pdf
- Terminal Type:
- Ferrule
- Current Rating:
- 15 A
- Short Description:
- 13/32" x 1-1/2", 600 VAC, 15 A, 200 kA Interrupt Rating, Ferrule Terminal, Class CC Rejection, Current Limiting, Time Delay Fuse
- Type:
- Class CC Rejection
- Voltage Rating:
- 600 VAC
- Interrupt Rating:
- 200 kA
- Diameter:
- 13/32
- Length:
- 1-1/2
- Approval:
- UL, CSA C22.2
- TS PIK:
- 110516808
- Country of Origin:
- Mexico
MSRP $33.72Surplus $18.02 -
Ferraz Shawmut TRS100R Fuses
MSRP $120.43Surplus $29.96SKU: F16-4873 Brand: Ferraz Shawmut MPN: TRS100R UPC: 78200174911 Shipping Weight: 0.60 lbs. Shipping Height: 2.00 In. Shipping Length: 8.00 In. Shipping Width: 2.00...- SKU:
- F16-4873
- TS PIK:
- 528425
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Series:
- TRS-R
- Short Description:
- 1.31" x 7.88", 600 VAC 50/60 Hz, 600 VDC, 100 A, 200 kA AC/100 kA DC Interrupt Rating, Fiberglass Body, Tin Plated Copper Blade Terminal, Class RK5, Clip Mount, Time Delay, Low Vage, UL Power Fuse
- Current Rating:
- 100 A
- Type:
- Class RK5
- CAD Drawings:
- Mersen_01361_1_CAD.pdf
- Terminal Type:
- Blade
- Characteristics:
- Time Delay, Low Vage
- Diameter:
- 1.31
- Length:
- 7.888
- Voltage Rating:
- 600 VAC 50/60 Hertz, 600 VDC
- Approval:
- UL 248-12, CSA C22.2
MSRP $120.43Surplus $29.96 -
Ferraz Shawmut TRS45R Fuses EA
MSRP $55.00Surplus $27.50Ferraz Shawmut TRS45R Fuses EA​ ARCA SKU: F16-2473 Brand: Ferraz Shawmut MPN: TRS45R UPC: 78200174902 Shipping Weight: 0.75 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- F16-2473
- Series:
- TRS-R
- Type:
- Class RK5
- Approval:
- UL 248-12
- Volts:
- 600 VAC
- Amps:
- 32 A
- Interrupting Rating:
- 200 kA
- Terminal Type:
- Ferrule
- Length:
- 5-1/2
- Diameter:
- 1-1/16
- Characteristics:
- Time Delay
- Time Delay:
- Voltage Rating
- Short Description:
- 1.06" x 5.5", 600 VAC 50/60 Hz/300 VDC, 45 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Copper Ferrule Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay
- Catalog:
- Mersen_00086_191_CAT.pdf
- Data Sheet:
- Mersen_00090_PF12_PF13_DATA.pdf
- CAD Drawing:
- Mersen_00105_1_CAD.pdf
- Current Rating:
- 45 A
- CAD Drawings:
- Mersen_00105_1_CAD.pdf
- Voltage Rating:
- 600 VAC, 300 VDC
MSRP $55.00Surplus $27.50 -
Mersen R636 Fuse Reducers and Clips EA
MSRP $38.95Surplus $19.48Mersen R636 Fuse Reducers and Clips EA​ ARCA SKU: F16-4123 Brand: Mersen MPN: R636 UPC: 78200175246 Shipping Weight: 0.50 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- F16-4123
- Type:
- Rejection
- Short Description:
- 30 A at 600 V Fuse, 60 A at 600 V Clip, 200 kA, Class R, Rejection, Fuse Reducer
- Fuse Type:
- Class R
- Catalog:
- Mersen_00041_J4_CAT.pdf
MSRP $38.95Surplus $19.48 -
Mersen TRS35R Fuses
MSRP $50.95Surplus $20.32Mersen TRS35R Fuses​ ARCA SKU: F16-1161 Brand: Mersen MPN: TRS35R UPC: 78200174900 Shipping Weight: 0.40 lbs. Shipping Height: 1.00 In. Shipping Length: 6.00 In...- SKU:
- F16-1161
- Approval:
- UL
- Amps:
- 35 A
- Diameter:
- 1.06
- Interrupting Rating:
- 200 kA
- Length:
- 5.5
- Terminal Type:
- Ferrule
- Type:
- Motor Circuit Protection
- Volts:
- 600 VAC/300 VDC
- Short Description:
- 1.06" x 5.5", 600 VAC, 300 VDC, 35 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Copper Ferrule Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Voltage UL Power Fuse
- Data Sheet:
- Mersen_00090_PF12_PF13_DATA.pdf
- CAD Drawing:
- Mersen_00105_1_CAD.pdf
- TS PIK:
- 528416
- CAD Drawings:
- Mersen_00105_1_CAD.pdf
- Current Rating:
- 35 A
- Voltage Rating:
- 600 VAC/300 VDC
MSRP $50.95Surplus $20.32 -
Bussmann LPN-RK-60SP Fuses EA
MSRP $71.00Surplus $10.19Bussmann LPN-RK-60SP Fuses EA​ ARCA SKU: F16-2754 Brand: Bussmann MPN: LPN-RK-60SP UPC: 30051712538412 Shipping Weight: 0.10 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- F16-2754
- Approval:
- UL
- Approval:
- CSA C22.2
- Approval:
- CE
- Characteristics:
- 10 Second Time Delay (at 500 Percent Rated Current)
- Characteristics:
- Dual Element
- Characteristics:
- Non-Indicating
- Characteristics:
- Current Limiting
- Amps:
- 60 A
- Diameter:
- 0.81
- Interrupting Rating:
- 300 kA (Symmetrical)
- Interrupting Rating:
- 100 Kiloamp DC
- Length:
- 3
- Terminal Type:
- Ferrule with Grooved Ring
- Type:
- Class RK1
- Volts:
- 250 VAC
- Volts:
- 125 VDC
- Short Description:
- 0.81" x 3", 250 VAC, 125 VDC, 60 A, 300/100 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK1, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)
- Series:
- LPN-RK
- Data Sheet:
- Eaton-Bussmann_00161_1-4_DATA.pdf
- Catalog:
- Eaton-Bussmann_00349_1_24_1_25_CAT.pdf
- Current Rating:
- 60 A
- Voltage Rating:
- 250 VAC, 125 VDC
- Interrupt Rating:
- 300/100 kA
- Country of Origin:
- Mexico
MSRP $71.00Surplus $10.19 -
Contact Us For Quote
Ferraz Shawmut R262 Fuse Reducers and Clips
MSRP $198.67Surplus $52.34Ferraz Shawmut R262 Fuse Reducers and Clips​ ARCA SKU: F16-3595 Brand: Ferraz Shawmut MPN: R262 UPC: 78200175239 Shipping Weight: 0.35 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- F16-3595
- Fuse Type:
- Class R
- Catalog:
- MERSENE00136_J3.pdf
- Series:
- R
- Short Description:
- 60 A at 250 V Fuse, 200 A at 250 V Clip, 200 kA, Class R, Rejection, Fuse Reducer
- Type:
- Rejection
MSRP $198.67Surplus $52.34
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
