Molded Case Breakers (MCCBs)
A molded case circuit breaker (MCCB) is a type of electrical breaker that is used to protect electrical systems from damage due to overloading, short-circuiting, or other electrical faults. MCCBs are commonly used in industrial and commercial electrical systems, and are designed to handle higher currents and voltage levels than residential miniature circuit breakers.
- Product
- Qty in Cart
- Price
-
Contact Us For Quote
Square D BJA160203 Molded Case Breakers (MCCBs)
MSRP $601.00Surplus $167.31Square D BJA160203 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-7075 Brand: Square D MPN: BJA160203 UPC: 60648115417 Shipping Weight: 1.80 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- C15-7075
- TS PIK:
- 109594402
- CAD Drawings:
- SchneiderElectric-SquareD_73649_1_CAD.pdf
- Frame Type:
- B
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 125 VDC
- Number of Poles:
- 1
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 125 VDC, 20 A, 25 kA, 1-Pole, B-Frame, B Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Series:
- BJ
- Interrupting Rating:
- 25 kA at 600 Star/347 V, 50 kA at 125 VDC
- Maximum AC Voltage Rating:
- 347 V
- Type:
- Thermal Magnetic
- Terminal Type:
- I-Line Connection Line Lug Load
- Maximum DC Voltage Rating:
- 125 V
- Installation/Operator:
- SchneiderElectric-SquareD_01071_INST.pdf
- Size:
- 1.06 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Current Rating:
- 20 A
- Data Sheet:
- SchneiderElectric-SquareD_35175_1-4_DATA.pdf
- Country of Origin:
- United States
- Prop 65 Warning:
- Yes
MSRP $601.00Surplus $167.31 -
Contact Us For Quote
Square D EHB14015 Molded Case Breakers (MCCBs)
MSRP $252.94Surplus $128.73Square D EHB14015 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-6515 Brand: Square D MPN: EHB14015 UPC: Shipping Weight: 0.40 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- C15-6515
MSRP $252.94Surplus $128.73 -
Contact Us For Quote
Square D HDA36060U33X Molded Case Breakers (MCCBs)
MSRP $1,512.00Surplus $498.96SKU: C15-7142 Brand: Square D MPN: HDA36060U33X UPC: 78590167430 Shipping Weight: 6.20 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00...- SKU:
- C15-7142
- TS PIK:
- 120072362
MSRP $1,512.00Surplus $498.96 -
Square D KA36175 Molded Case Breakers (MCCBs)
MSRP $4,700.00Surplus $853.70SKU: C15-7081 Brand: Square D MPN: KA36175 UPC: Shipping Weight: 7.50 lbs. Shipping Height: 5.00 In. Shipping Length: 12.00 In. Shipping Width: 5.00 In. Product...- SKU:
- C15-7081
- Current Rating:
- 175 A
- Short Description:
- 600 VAC, 250 VDC, 175 A, 22 kA, 3-Pole, K-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Series:
- 655/825/660, kA
- Voltage Rating:
- 600 VAC, 250 VDC
- Catalog:
- SchneiderElectric-SquareD_00935_11_12_11_13_CAT.pdf
- Type:
- Molded Case, Thermal Magnetic, Main
- Number of Poles:
- 3
- Interrupting Rating:
- 42 kA at 240 VAC, 25 kA at 480 VAC, 22 kA at 600 VAC
MSRP $4,700.00Surplus $853.70 -
Contact Us For Quote
Eaton EDB3150L Molded Case Breakers (MCCBs) 3P 150A
MSRP $1,692.17Surplus $482.79SKU: C15-5239 Brand: Eaton MPN: EDB3150L UPC: 78211697615 Shipping Weight: 4.40 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-5239
- Amps:
- 175 A
- Poles:
- 3
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, ED, COMPLETE BREAK
- TS PIK:
- 21331466
- Series:
- C
- Country of Origin:
- Dominican Republic
MSRP $1,692.17Surplus $482.79 -
Contact Us For Quote
Eaton FDB2100 Molded Case Breakers (MCCBs) FDB 2P 100A 600V 50/60Hz 2Ph F Frame
MSRP $1,195.00Surplus $355.10SKU: C15-1810 Brand: Eaton MPN: FDB2100 UPC: 786679312469 Shipping Weight: 2.65 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In...- SKU:
- C15-1810
- Series:
- C
- Volts:
- 600 V
- Amps:
- 100 A
- Poles:
- 2
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- Series C complete molded case circuit breaker, F-frame, FDB, Complete breaker, Fixed thermal, fixed magnetic trip type, Two-pole, 100A, 600 Vac
- Number of Poles:
- 2
- Frame Type:
- F
- Voltage Rating:
- 600 VAC
- Current Rating:
- 100 A
MSRP $1,195.00Surplus $355.10 -
Eaton NZMB1-A63 Molded Case Breakers (MCCBs) EA
MSRP $1,510.47Surplus $182.40Eaton NZMB1-A63 Molded Case Breakers (MCCBs) EA​ ARCA SKU: C15-6727 Brand: Eaton MPN: NZMB1-A63 UPC: 4015082590772 Shipping Weight: 2.35 lbs. Shipping Height: 4.00 In. Shipping...- SKU:
- C15-6727
- Approval:
- UL489
- Approval:
- CSA C22.2
- Approval:
- CE
- Amps:
- 63 A
- Frame:
- NZM1
- Interrupting Rating:
- 25 kA
- Maximum AC Voltage:
- 440
- Poles:
- 3
- Size:
- 90 Millimeter Width x 84.5 Millimeter Depth x 145 Millimeter Height
- Terminal Type:
- Front Frame ClA
- Terminal Type:
- Box
- Type:
- Thermal Magnetic
- Type:
- Adjustable Thermal
- Volts:
- 440 VAC
- Short Description:
- 440 VAC 50/60 Hz, 63 A, 25 kA, 3-Pole, Front Frame ClA/Box Terminal, NZM1 Frame, Thermal Magnetic, Molded Case Circuit Breaker
- Series:
- NZMB1
- Specification/Technical:
- Eaton-Moeller_00207_1_2_SPEC.pdf
- Data Sheet:
- Eaton-Moeller_01024_1-9_DATA.pdf
- Frame Type:
- NZM1
- Current Rating:
- 63 A
- Installation/Operator:
- Eaton-Moeller_00020_INST.pdf
- Number of Poles:
- 3
- Voltage Rating:
- 440 VAC
- Catalog:
- Eaton-Moeller_00013_59_CAT.pdf
- Maximum AC Voltage Rating:
- 440
- Country of Origin:
- Germany
MSRP $1,510.47Surplus $182.40 -
GE TEY340 Molded Case Breakers (MCCBs) TEY 3P 40A 480V 50/60Hz 3Ph
MSRP $682.17Surplus $260.24SKU: C15-3532 Brand: GENERAL ELECTRIC MPN: TEY340 UPC: 78316418105 Shipping Weight: 2.05 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 4.00...- SKU:
- C15-3532
- Frame Type:
- TEY
- Voltage Rating:
- 120/240/277 VAC
- Current Rating:
- 32 A
- Number of Poles:
- 3
- Interrupting Rating:
- 14 kA at 277 VAC,65 kA at 120/240 VAC
- Type:
- Thermal Magnetic
- Short Description:
- 480 Star/277 VAC, 40 A, 65 kA at 120/240 VAC, 14 kA at 277 VAC, 10 to 4 AWG Copper/Aluminum, 3-Pole, Non-Interchangeable Trip, Compact, Thermal Magnetic, Industrial
- Catalog:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_00015_6_9_6_64_CAT.pdf
- Specification/Technical:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_00261_1_2_SPEC.pdf
- Approval:
- UL
MSRP $682.17Surplus $260.24 -
Crouse-Hinds HFD1020L Molded Case Breakers (MCCBs) 1P 20A
MSRP $736.23Surplus $246.46Crouse-Hinds HFD1020L Molded Case Breakers (MCCBs) 1P 20A​ ARCA SKU: C15-5409 Brand: Crouse-Hinds MPN: HFD1020L UPC: 78667939824 Shipping Weight: 1.55 lbs. Shipping Height: 4.00 In...- SKU:
- C15-5409
- Voltage Rating:
- 277 VAC 50/60 Hertz, 125 VDC
- Terminal Type:
- Line and Load
- Interrupting Rating:
- 65 kA at 277 VAC, 10 kA at 125 VDC (UL), 65 kA at 220/240 VAC, 10 kA at 125 VDC (IEC)
- Maximum DC Voltage Rating:
- 125 V
- Type:
- Fixed Thermal Magnetic, Molded Case
- Size:
- 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Number of Poles:
- 1
- Installation/Operator:
- Eaton_00091_INST.pdf
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, HFD, COMPLETE BREA
- CAD Drawings:
- Eaton_41228_1_CAD.pdf
- Current Rating:
- 20 A
- Maximum AC Voltage Rating:
- 277 V
- Frame Type:
- FD
MSRP $736.23Surplus $246.46 -
Eaton EHD2050 Molded Case Breakers (MCCBs) 2P 50A 480V EA
MSRP $749.97Surplus $505.40Eaton EHD2050 Molded Case Breakers (MCCBs) 2P 50A 480V EA​ ARCA SKU: C15-2311 Brand: Eaton MPN: EHD2050 UPC: 78667931747 Shipping Weight: 3.05 lbs. Shipping Height: 4.00 In...- SKU:
- C15-2311
- Series:
- EHD
- Type:
- Thermal Magnetic
- Type:
- Compact
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 480 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 2
- Interrupting Rating:
- 14 kA at 480 VAC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC
- Terminal Type:
- Standard Pressure Line and Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 480 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 480 VAC 50/60 Hz, 250 VDC, 50 A, 14/10 kA, 2-Pole, Standard Pressure Load Terminal, EHD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Installation/Operator:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_00024_INST.pdf
- CAD Drawing:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_01786_1_CAD.pdf
- TS PIK:
- 21509168
- Number of Poles:
- 2
- Voltage Rating:
- 480 VAC 50/60 Hertz, 250 VDC
- Data Sheet:
- Eaton_40755_1-4_DATA.pdf
- Current Rating:
- 50 A
- Country of Origin:
- Dominican Republic
MSRP $749.97Surplus $505.40 -
Contact Us For Quote
Eaton HKD3300WC01512 Molded Case Breakers (MCCBs) HKD 3P 300A 600V 50/60Hz 3Ph K Frame
MSRP $120,000.00Surplus $31,373.51SKU: C15-4711 Brand: Eaton MPN: HKD3300WC01512 UPC: Shipping Weight: 10.75 lbs. Shipping Height: 5.00 In. Shipping Length: 12.00 In. Shipping Width: 10.00 In...- SKU:
- C15-4711
- Frame Type:
- K
- Voltage Rating:
- 600 V
- Current Rating:
- 300 A
- Number of Poles:
- 3
- Interrupting Rating:
- 100 kA at 240 Vac, 65 kA at 480 Vac
- Short Description:
- Eaton Series C complete molded case circuit breaker, K-frame, HKD, Complete breaker, Fixed thermal, fixed magnetic trip, Three-pole, 300A, 600 Vac, 250 Vdc, 100 kA at 240 Vac, 65 kA at 480 Vac, Without terminals, 50/60 Hz
MSRP $120,000.00Surplus $31,373.51 -
Eaton LD3600 Molded Case Breakers (MCCBs) 3P 600A
MSRP $12,981.77Surplus $4,883.76SKU: C15-6808 Brand: Eaton MPN: LD3600 UPC: 78667934182 Shipping Weight: 21.85 lbs. Shipping Height: 8.00 In. Shipping Length: 14.00 In. Shipping Width: 11.00 In...- SKU:
- C15-6808
- TS PIK:
- 21010546
- Current Rating:
- 600 A
- Terminal Type:
- Aluminum/Copper Standard Pressure Line and Load Terminal
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_323_V4T2_324_CAT.pdf
- Voltage Rating:
- 600 VAC, 250 VDC
- Number of Poles:
- 3
- Type:
- Molded Case, Thermal Magnetic
- Installation/Operator:
- Eaton_00486_INST.pdf
- Frame Type:
- LD
- Interrupting Rating:
- 35 kA at 480 VAC
- Size:
- 8.25 Inch Width x 4.06 Inch Depth x 10.75 Inch Height
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 600 V
- Series:
- C, LD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 600 A, 35 kA, 3-Pole, LD Frame, Thermal Magnetic, Molded Case, Interchangeable Trip Circuit Breaker
MSRP $12,981.77Surplus $4,883.76 -
Eaton LG3600 Molded Case Breakers (MCCBs) EA
MSRP $7,700.00Surplus $2,800.03SKU: C15-9644 Brand: Eaton MPN: LG3600 UPC: 786679659236 Shipping Weight: 22.95 lbs. Shipping Height: 8.00 In. Shipping Length: 11.00 In. Shipping Width: 14.00 In...- SKU:
- C15-9644
- TS PIK:
- 107005285
- Country of Origin:
- United States
MSRP $7,700.00Surplus $2,800.03 -
Contact Us For Quote
GE EZSEHA36AT0030 Molded Case Breakers (MCCBs)
MSRP $1,000.00Surplus $224.38SKU: C15-11279 Brand: GE MPN: EZSEHA36AT0030 UPC: Shipping Weight: 8.10 lbs. Shipping Height: 6.00 In. Shipping Length: 12.00 In. Shipping Width: 10.00 In. Product...- SKU:
- C15-11279
- TS PIK:
- 126994276
MSRP $1,000.00Surplus $224.38 -
Contact Us For Quote
GE EZSEHA36AT0150 Molded Case Breakers (MCCBs)
MSRP $2,200.00Surplus $493.63SKU: C15-11288 Brand: GE MPN: EZSEHA36AT0150 UPC: Shipping Weight: 8.10 lbs. Shipping Height: 6.00 In. Shipping Length: 12.00 In. Shipping Width: 10.00 In. Product...- SKU:
- C15-11288
- TS PIK:
- 126994279
MSRP $2,200.00Surplus $493.63 -
Contact Us For Quote
GE EZSFLA36AT0250 Molded Case Breakers (MCCBs)
MSRP $3,500.00Surplus $785.32SKU: C15-11287 Brand: GE MPN: EZSFLA36AT0250 UPC: Shipping Weight: 12.25 lbs. Shipping Height: 6.00 In. Shipping Length: 16.00 In. Shipping Width: 10.00 In. Product...- SKU:
- C15-11287
- TS PIK:
- 126994181
MSRP $3,500.00Surplus $785.32 -
GENERAL ELECTRIC THED113020 Molded Case Breakers (MCCBs) EA
MSRP $1,069.25Surplus $100.34GENERAL ELECTRIC THED113020 Molded Case Breakers (MCCBs) EA​ ARCA SKU: C15-3082 Brand: GENERAL ELECTRIC MPN: THED113020 UPC: 78316413867 Shipping Weight: 1.45 lbs. Shipping Height: 4...- SKU:
- C15-3082
- TS PIK:
- 112128663
- Installation/Operator:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_00116_INST.pdf
- CAD Drawings:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_04182_1_CAD.pdf
- Short Description:
- 277 VAC, 20 A, 65 kA, 1-Pole, Copper/Aluminum Load Lug Terminal, Thermal Magnetic, Non-Interchangeable, Molded Case Circuit Breaker
- Catalog:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_01912_6_67_CAT.pdf
- Terminal Type:
- Copper/Aluminum Load Lug
- Current Rating:
- 20 A
- Number of Poles:
- 1
- Type:
- Thermal Magnetic
MSRP $1,069.25Surplus $100.34 -
Square D EHB14020 Molded Case Breakers (MCCBs)
MSRP $421.56Surplus $119.05Square D EHB14020 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-6516 Brand: Square D MPN: EHB14020 UPC: Shipping Weight: 0.40 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- C15-6516
- Type:
- Thermal Magnetic, Molded Case
- Short Description:
- 277 VAC, 20 A, 14 kA, 1-Pole, Bolt-on Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Voltage Rating:
- 277 VAC
- Interrupting Rating:
- 14 kA at 277 V
- Number of Poles:
- 1
- Series:
- EHB
- Catalog:
- SQAREDE84937_2.pdf
- Current Rating:
- 20 A
- Size:
- 0.99 Inch Width x 2.9 Inch Depth x 3.51 Inch Height
MSRP $421.56Surplus $119.05 -
Square D HJA36090 Molded Case Breakers (MCCBs)
MSRP $2,225.00Surplus $1,079.96SKU: C15-7150 Brand: Square D MPN: HJA36090 UPC: 78590150724 Shipping Weight: 5.50 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-7150
- TS PIK:
- 127230906
- Current Rating:
- 90 A
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 90 A, 25 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Interrupting Rating:
- 25 kA at 600 VAC, 20 kA at 250 VDC
- Series:
- HJ
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric_29672_1_CAD.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Data Sheet:
- SchneiderElectric-SquareD_46754_1-3_DATA.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Number of Poles:
- 3
- Prop 65 Warning:
- Yes
- Country of Origin:
- Canada
MSRP $2,225.00Surplus $1,079.96 -
Square D QBA32125 Molded Case Breakers (MCCBs)
MSRP $1,913.00Surplus $863.17SKU: C15-7225 Brand: Square D MPN: QBA32125 UPC: 78590140518 Shipping Weight: 6.80 lbs. Shipping Height: 6.00 In. Shipping Length: 12.00 In. Shipping Width: 8.00 In...- SKU:
- C15-7225
- TS PIK:
- 120071915
- Number of Poles:
- 3
- Installation/Operator:
- SchneiderElectric-SquareD_02030_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_9_57_CAT.pdf
- Type:
- Thermal Magnetic
- Interrupting Rating:
- 10 kA at 240 VAC
- Series:
- QB
- Data Sheet:
- SchneiderElectric_15643_1_2_DATA.pdf
- Voltage Rating:
- 240 VAC 50/60 Hertz
- CAD Drawings:
- SchneiderElectric_30259_1_CAD.pdf
- Current Rating:
- 125 A
- Short Description:
- 240 VAC 50/60 Hz, 125 A, 10 kA, 3-Pole, Q-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Panelboard Molded Case Circuit Breaker
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
MSRP $1,913.00Surplus $863.17
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
